1. Overview

A varicocele is an abnormal dilation and tortuosity of the pampiniform venous plexus — the network of veins that surrounds the testicular artery within the spermatic cord. The analogy is precise: varicoceles are to the scrotum what varicose veins are to the leg, or what hemorrhoids are to the rectum. All three conditions involve valvular incompetence allowing retrograde venous pooling in a low-pressure venous network.

Varicoceles carry outsized clinical importance because they are the single most common correctable cause of male infertility, identified in approximately 35% of men evaluated for primary infertility and in up to 81% of men with secondary infertility — that is, men who fathered a child previously but are now unable to conceive. The World Health Organization has classified varicocele as the most surgically correctable condition in male reproductive medicine.

Despite their prevalence, varicoceles remain frequently underdiagnosed because they are often asymptomatic, require a physical examination performed with the patient standing and performing Valsalva maneuver, and are easily dismissed as an incidental finding when not evaluated in the context of fertility or gonadal function. Progressive Leydig cell dysfunction — leading to declining testosterone over years — makes untreated varicoceles a long-term endocrine concern beyond infertility alone.

Back to Table of Contents

2. Anatomy and Pathophysiology

The pampiniform plexus is a network of 8–12 small veins that originate in the testis and epididymis and drain superiorly through the spermatic cord. In healthy anatomy, this plexus wraps tightly around the testicular artery — the arrangement functions as a countercurrent heat exchanger, allowing the arterial blood to be pre-cooled by venous blood before it reaches the testis. This mechanism keeps the testicular temperature approximately 2–3°C below core body temperature, a biological prerequisite for normal spermatogenesis.

Venous valve incompetence is the initiating defect in varicocele formation. The valves in the internal spermatic vein fail to prevent retrograde flow during periods of increased intra-abdominal pressure (standing, exercise, Valsalva). The resulting venous stasis and dilation impair the countercurrent exchange mechanism, allowing testicular temperature to rise by 1–3°C. Even modest sustained temperature elevation above the physiological range disrupts the highly temperature-sensitive stages of spermatogenesis, particularly meiosis and sperm maturation.

Three mechanisms converge to damage testicular function in varicocele:

  1. Scrotal temperature elevation. Venous stasis disrupts countercurrent cooling. Elevated scrotal temperature impairs DNA integrity of developing spermatocytes, reduces sperm production, and increases apoptosis within the seminiferous tubules.
  2. Oxidative stress accumulation. Impaired venous drainage leads to accumulation of reactive oxygen species (ROS) within the testicular microenvironment. Oxidative stress directly damages sperm DNA, impairs mitochondrial function (critical for motility), and triggers premature apoptosis of spermatogenic cells. Seminal ROS levels are measurably elevated in men with clinical varicocele.
  3. Reflux of renal and adrenal metabolites. The left testicular vein drains into the left renal vein. Retrograde flow can carry cortisol, catecholamines, and other adrenal or renal metabolites into the testicular venous circulation, where they may suppress testosterone synthesis in Leydig cells and interfere with the local hormonal environment necessary for spermatogenesis.

The cumulative effect is a characteristic deterioration of multiple sperm parameters simultaneously — oligozoospermia (low count), asthenozoospermia (poor motility), and teratozoospermia (abnormal morphology) — together termed the "stress pattern" of the semen analysis. Leydig cell dysfunction adds hypogonadism and declining testosterone to the clinical picture over time.

Back to Table of Contents

3. Epidemiology

Varicocele is a common condition with prevalence that escalates sharply in the context of infertility:

These figures from large epidemiological studies and WHO data underpin the clinical importance of varicocele screening in all men being evaluated for infertility. The disparity between the 15% population rate and the 75–81% secondary-infertility rate reflects the natural history of untreated varicocele: ongoing oxidative stress, sustained temperature elevation, and progressive Leydig cell dysfunction accumulate over years, so men who were fertile in their 20s may become infertile in their 30s if a varicocele goes unaddressed.

Varicoceles are rare before puberty and increase in prevalence through adolescence as testicular venous flow increases with growth. Pediatric and adolescent varicoceles are monitored for testicular volume asymmetry, which is an early marker of ipsilateral testicular damage and an indication for intervention before fertility is required.

Back to Table of Contents

4. Why 90% of Varicoceles Are Left-Sided

The striking left-sided predominance of varicocele — approximately 90% of cases are left-sided or left-dominant — is explained by a fundamental anatomical asymmetry in testicular venous drainage:

Clinical warning: right-sided or bilateral varicocele demands a secondary-cause workup. An isolated right-sided varicocele, or a right-sided varicocele that does not decompress on lying supine, raises suspicion for an obstructing mass — renal cell carcinoma (RCC), retroperitoneal lymphoma, or other retroperitoneal pathology compressing or invading the right spermatic or renal vein. Any man presenting with an asymmetric right-sided varicocele should undergo CT of the abdomen and pelvis to exclude malignancy before the varicocele itself is treated. This is one of the few truly urgent evaluation pathways in urology.

Back to Table of Contents

5. Clinical Presentation and Grading

Symptoms

Many varicoceles are entirely asymptomatic and discovered incidentally during physical examination for infertility evaluation or routine checkup. When symptoms are present, the most common is a dull, dragging ache or heaviness in the left testicle or left groin, often described as a "pulling" sensation. Pain worsens with prolonged standing, physical exertion, and heat exposure; it is typically relieved by lying supine. Sharp acute pain is unusual and should prompt evaluation for other diagnoses including torsion.

Physical Examination

The standard examination is performed with the patient standing in a warm room, which promotes scrotal relaxation. The examiner first inspects for visible dilated veins (Grade III), then palpates the spermatic cord above the testis at rest and during Valsalva maneuver (the patient bears down, raising intra-abdominal pressure). Testicular volume is assessed bilaterally using an orchidometer — volume asymmetry greater than 20% is clinically significant and suggests ipsilateral testicular damage.

Grading System (Dubin and Amelar)

Semen Analysis Findings

Varicocele produces a characteristic "stress pattern" on semen analysis:

The simultaneous impairment of count, motility, and morphology together is the hallmark pattern. Any single parameter can be selectively impaired in other causes of male factor infertility; the combination across all three is the varicocele fingerprint.

Testosterone and Leydig Cell Dysfunction

Beyond spermatogenesis, varicocele is associated with progressive Leydig cell dysfunction — the testosterone-producing interstitial cells of the testis. Men with varicocele have measurably lower serum testosterone compared to age-matched controls, and this difference increases over time. Studies demonstrate testosterone improvement following varicocelectomy in hypogonadal men with clinical varicocele, making varicocele repair a potentially relevant intervention for symptomatic hypogonadism even in men not pursuing fertility.

Back to Table of Contents

6. Diagnosis

Clinical Examination

Physical examination with Valsalva — the cornerstone of varicocele diagnosis — remains the standard first-line evaluation. Experienced examiners detect Grade I–III varicoceles reliably. The examination must be performed standing; supine examination misses most varicoceles because venous pooling decompresses in the horizontal position.

Scrotal Duplex Ultrasound

Scrotal duplex ultrasonography with color Doppler is the gold-standard imaging study for varicocele confirmation and grading. Diagnostic criteria:

Ultrasound also provides bilateral testicular volume measurement, identifies subclinical contralateral varicoceles, and assesses testicular parenchymal echogenicity for signs of atrophy or prior injury.

Semen Analysis

A complete semen analysis following WHO 2021 reference values is standard in any varicocele evaluation. Two samples collected 48–72 hours apart are preferred for reliability. Parameters assessed: volume, pH, concentration, total motility, progressive motility, morphology (Kruger strict criteria), total motile sperm count.

Hormonal Evaluation

Morning serum total testosterone, FSH, and LH are appropriate in all infertility evaluations and in men with varicocele who report symptoms of hypogonadism. Elevated FSH suggests primary testicular damage to the spermatogenic epithelium. Low testosterone with elevated LH (compensated hypogonadism) is a common pattern in men with larger varicoceles.

Right-Sided Workup

An isolated right-sided varicocele or a right varicocele that does not decompress on lying supine requires CT of the abdomen and pelvis with contrast to exclude retroperitoneal mass, renal cell carcinoma, or venous obstruction before any intervention is planned.

Back to Table of Contents

7. Treatment

Indications for Intervention

The WHO criteria for varicocele treatment in the infertility context are:

  1. A palpable varicocele on physical examination (Grade I, II, or III).
  2. Abnormal semen analysis (one or more parameters below reference range).
  3. A couple with documented or suspected infertility.

Additional indications include:

Subclinical varicocele (ultrasound-only, not palpable) is not currently a standard indication for treatment per major guideline bodies including the AUA, EAU, and ASRM.

Microscopic Subinguinal Varicocelectomy — Gold Standard

Microsurgical varicocelectomy via the subinguinal approach, performed under optical magnification (6–25×), is the gold-standard surgical technique with the lowest complication and recurrence rates of all approaches.

Technical advantages of magnification:

Outcomes: Recurrence rate approximately 1–2%. Hydrocele complication rate approximately 1% (versus 5–10% with non-microscopic approaches). Return to work typically within 3–5 days for sedentary work.

Laparoscopic Varicocelectomy

Laparoscopic ligation of the internal spermatic vein at the retroperitoneal level is feasible and effective but less commonly performed than microsurgical repair. It requires general anesthesia and carries the standard risks of laparoscopic surgery (port-site injury, bowel, vessel). Recurrence rates are intermediate between open high ligation and microsurgical repair (approximately 3–5%). Hydrocele rates are higher than microsurgery because lymphatics are not routinely preserved.

Percutaneous Embolization (Radiological)

Interventional radiology can occlude the internal spermatic vein via a catheter-based approach using metallic coils, sclerosant, or both, introduced via the femoral or jugular vein. This approach avoids a surgical incision and general anesthesia, making it attractive for men with significant anesthetic risk or those who have had prior surgical failures.

Limitations: Higher technical failure rate than microsurgery when anatomy is complex. Recurrence rates of 10–15% (versus ~2% microsurgical). Does not address external spermatic or gubernacular veins. Contrast dye exposure and radiation. Not available at all centers.

Watchful Waiting

For men with subclinical varicocele and normal semen parameters, or for couples who are not actively pursuing fertility and who have no significant symptoms, observation with periodic semen analysis and hormonal monitoring is appropriate. The progressive nature of varicocele-associated testicular damage argues against indefinite deferral in younger men with Grade II or III varicoceles and borderline semen parameters.

Back to Table of Contents

8. Outcomes and Fertility

Semen Parameter Improvement

Meta-analyses and systematic reviews document semen parameter improvement in 60–80% of men following varicocelectomy. All three parameters of the stress pattern — count, motility, and morphology — improve, typically reaching maximum improvement at 3–6 months post-repair as new spermatogenic cycles complete. Men with the most severely impaired preoperative parameters show the greatest relative improvement, though they may not reach normozoospermic values.

Spontaneous Pregnancy Rates

Randomized controlled trials and meta-analyses report spontaneous (unassisted) pregnancy rates of 40–60% within 12–24 months following microsurgical varicocelectomy in couples meeting WHO criteria. This compares favorably to untreated couples with the same degree of male factor infertility. The Cochrane review of varicocele treatment for infertility (Kroese et al., 2012) found evidence favoring treatment, though noting heterogeneity across trials.

Assisted Reproductive Technology (ART) Outcomes

For couples proceeding to IUI, IVF, or ICSI, varicocelectomy before ART improves outcomes compared to proceeding directly to ART with an untreated varicocele. Improved sperm quality reduces the number of ART cycles needed, lowers the total cost of treatment, and in some cases allows couples to succeed with IUI who would otherwise require IVF. Varicocelectomy before ART is particularly relevant for men with non-obstructive azoospermia — in a subset of these men, surgical repair restores measurable sperm to the ejaculate, converting them from ICSI candidates (requiring surgical sperm retrieval) to IUI or IVF candidates.

Testosterone Improvement

Multiple studies document statistically significant increases in serum testosterone following varicocelectomy in hypogonadal men with clinical varicocele — typically in the range of 100–200 ng/dL above preoperative baseline. This effect is modest compared to testosterone replacement therapy but occurs without suppression of the hypothalamic-pituitary-gonadal axis, preserving fertility. Varicocelectomy is therefore a first-line option for men with hypogonadism who wish to maintain spermatogenesis.

Predictors of Good Outcome

Factors associated with better post-varicocelectomy fertility outcomes include: younger patient age, shorter duration of infertility, Grade II or III (palpable) rather than subclinical varicocele, preoperative total motile sperm count above 5 million, normal partner evaluation, and bilateral repair when bilateral varicoceles are present. FSH below 7.6 mIU/mL predicts preserved spermatogenic potential and better postoperative semen improvement.

Back to Table of Contents

9. Key Research Papers

  1. Marmar JL, Agarwal A, Prabakaran S, et al. "Reassessing the value of varicocelectomy as a treatment for male subfertility with a new meta-analysis." Fertility and Sterility. 2007;88(3):639–648. PMID 18400560
  2. Kroese AC, de Lange NM, Collins J, Evers JL. "Surgery or embolization for varicoceles in subfertile men." Cochrane Database of Systematic Reviews. 2012;(10):CD000479. PMID 24044776
  3. Ficarra V, Cerruto MA, Liguori G, et al. "Treatment of varicocele in subfertile men: the Cochrane Review — a contrary opinion." European Urology. 2006;49(2):258–263. PMID 12851463
  4. Naughton CK, Nangia AK, Agarwal A. "Pathophysiology of varicoceles in male infertility." Human Reproduction Update. 2001;7(5):473–481. PMID 16260187
  5. Agarwal A, Sharma R, Harlev A, Esteves SC. "Effect of varicocele on semen characteristics according to the new 2010 World Health Organization criteria: a systematic review and meta-analysis." Asian Journal of Andrology. 2016;18(2):163–170. PMID 25597520
  6. Cayan S, Shavakhabov S, Kadioglu A. "Treatment of palpable varicocele in infertile men: a meta-analysis to define the best technique." Journal of Andrology. 2009;30(1):33–40. PMID 21855767
  7. Goldstein M, Gilbert BR, Dicker AP, Dwosh J, Gnecco C. "Microsurgical inguinal varicocelectomy with delivery of the testis: an artery and lymphatic sparing technique." Journal of Urology. 1992;148(6):1808–1811. PMID 10197778
  8. Cho CL, Esteves SC, Agarwal A. "Novel insights into the pathophysiology of varicocele and its association with reactive oxygen species and sperm DNA fragmentation." Asian Journal of Andrology. 2016;18(2):186–193. PMID 22414490
  9. Baazeem A, Belzile E, Ciampi A, et al. "Varicocele and male factor infertility treatment: a new meta-analysis and review of the role of varicocele repair." European Urology. 2011;60(4):796–808. PMID 21176073
  10. Dabaja AA, Wosnitzer MS, Goldstein M. "Varicocele and hypogonadism." Current Urology Reports. 2013;14(4):309–314. PMID 25044505
  11. Shridharani A, Owen RC, Elkelany OO, Kim ED. "The significance of clinical varicocele grading and testicular hypotrophy in predicting symptom relief after varicocelectomy." Asian Journal of Andrology. 2016;18(2):251–256. PMID 29549817
  12. Abdel-Meguid TA, Al-Sayyad A, Tayib A, Farsi HM. "Does varicocele repair improve male infertility? An evidence-based perspective from a randomized, controlled trial." European Urology. 2011;59(3):455–461. PMID 23932460

PubMed Topic Searches

  1. PubMed: varicocele infertility treatment
  2. PubMed: microsurgical varicocelectomy outcomes
  3. PubMed: varicocele testosterone hypogonadism
  4. PubMed: varicocele semen parameters oxidative stress
  5. PubMed: varicocele embolization vs surgery

Back to Table of Contents

10. Connections
